Docker Container Support

Docker whale

Infix comes with native support for Docker containers using podman. The YANG model describes the current level of support, complete enough to run both system and application containers.

Key design features of Infix, like using Linux switchdev, allow users to assign switch ports directly to containers, not just bridged VETH pairs. This is a rare and in many cases unique feature of Infix.

All network specific settings are done using the IETF interfaces YANG model, with augments for containers to ensure smooth integration with container networking in podman.

Important

Even though the podman command can be used directly from a shell prompt, we strongly recommend using the CLI commands instead. They employ the services of a wrapper container script which handles the integration of Docker containers in the system.

Caution

A word of warning. Containers can run on your system in privileged mode, as root, giving them full access to devices on your system. Even though containers are fenced from the host with Linux namespaces, resource limited using cgroups, and normally run with capped privileges, a privileged container is relatively easy to break out of. A trivial example is given in the Advanced section of this document.

We recommend avoiding privileged containers, if possible (they do have valid use-cases) and instead use capabilities.

Remember:

  • If the system is compromised, containers can be used to easily install malicious software in your system and over the network
  • Your system is as secure as anything you run in the container
  • If you run containers, there is no security guarantee of any kind
  • Running 3rd party container images on your system could open a security hole/attack vector/surface
  • An expert with knowledge how to build exploits will be able to jailbreak/elevate to root even if best practices are followed

This being said, a system suspected of being compromised can always be restored to a safe state with a factory reset. Provided, of course, that it has secure boot enabled.

Getting Started

In the CLI, containers can be run in one of two ways:

  1. container run IMAGE [COMMAND], or
  2. enter configure context, then edit container NAME

The first is useful mostly for testing, or running single commands in an image. It is a wrapper for podman run -it --rm ....

The second creates a read-only container that by default automatically start at every boot. It basically wraps podman create ....

When non-volatile storage is needed two complementary options exist:

  • Volumes: data stored in a volume is persisted until explicitly removed from the configuration, i.e., across host reboots and container upgrades
  • Content Mounts: where the content of a file mounted into the container is kept along with the container configuration in the device's startup-config

Podman ensures (using tmpfs) all containers have writable directories for certain critical file system paths: /dev, /dev/shm, /run, /tmp, and /var/tmp. Meaning, what you most often need is writable volumes for /var/lib and /etc, or only file mounts for a few files in /etc. The actual requirements depend on your container image and application to run.

Important

When running containers from public registries, double-check that they support the CPU architecture of your host system. Remember, unlike virtualization, containers reuse the host's CPU and kernel.

Hello World

Example: Hello World

Classic Hello World:

admin@example:/> container run docker://hello-world
Starting docker://hello-world :: use Ctrl-p Ctrl-q to detach
Trying to pull docker.io/library/hello-world:latest...
Getting image source signatures
Copying blob c1ec31eb5944 done
Copying config d2c94e258d done
Writing manifest to image destination
Storing signatures

Hello from Docker!
This message shows that your installation appears to be working correctly.

Example: Web Server

A web server with nginx, using standard docker bridge. Podman will automatically create a VETH pair for us, connecting the container to the docker0 bridge:

admin@example:/> configure
admin@example:/config/> edit interface docker0
admin@example:/config/interface/docker0/> set container-network
admin@example:/config/interface/docker0/> end
admin@example:/config/> edit container web
admin@example:/config/container/web/> set image docker://nginx:alpine
admin@example:/config/container/web/> set network publish 8080:80
admin@example:/config/container/web/> set network interface docker0
admin@example:/config/container/web/> set volume cache target /var/cache
admin@example:/config/container/web/> leave
admin@example:/> show container

Exit to the shell and verify the service with curl, or try to attach to your device's IP address using your browser:

admin@example:~$ curl http://localhost:8080

or connect to port 8080 of your running Infix system with a browser. See the following sections for how to add more interfaces and manage your container at runtime.

Container Images

The underlying podman project supports importing and fetching images in a variety of ways, the most common ones are also supported by Infix. In this section we present how to use them and in the next section we show how to upgrade to a newer base image.

The CLI help shows:

admin@example:/config/container/system/> help image
NAME
    image <string>

DESCRIPTION
    Docker image for the container: [transport]name[:tag|@digest]

    quay.io/username/myimage     -- Pull myimage:latest
    docker://busybox             -- Pull busybox:latest from Docker Hub
    docker://ghcr.io/usr/img     -- Pull img:latest from GitHub packages
    dir:/media/usb/myimage:1.1   -- Use myimage v1.1 from USB media
    docker-archive:/tmp/archive  -- Use archive:latest from tarball
    oci-archive:/lib/oci/archive -- Use archive:latest from OCI archive
                                    May be in .tar or .tar.gz format

    Additionally, the following URIs are also supported for setups
    that do not use a HUB or similar.  Recommend using 'checksum'!

    ftp://addr/path/to/archive   -- Downloaded using wget
    http://addr/path/to/archive  -- Downloaded using curl
    https://addr/path/to/archive -- Downloaded using curl

    Note: if a remote repository cannot be reached, the creation of the
          container will be put on a queue that retries pull every time
          there is a route change in the host's system.

Tip

The built-in help system in the CLI is generated from the YANG model, so the same information is also available for remote NETCONF users.

The two most common variants are docker:// and oci-archive:/.

The former requires a working Docker registry and the latter operates on a plain OCI archive. Infix does not come with a built-in registry, so the docker:// option is best used with external services, which in turn require networking to be up. In a deployment phase the easiest may be to set up a single interface on your host system with DHCP client.

The default method is docker://, so when setting the image for your container, you can omit the docker:// prefix. You can also use the admin-exec command container pull docker://..., and when configuring a container podman will check first if it has the image before trying to download anything. (See also the upgrade section, below.)

The oci-archive:/ is interesting since many users may not have, or do not want to, publish their images in a registry. Use the Docker OCI exporter or any other tool that supports generating OCI Image format. Infix supports loading both .tar or .tar.gz formats.

Here we show a simple example of fetching an OCI image to the system, but many others exist, tools like wget, curl, and scp come to mind.

Shell OCI Example:

admin@example:~$ cd /var/tmp/
admin@example:/var/tmp$ sudo wget https://github.com/kernelkit/curiOS/releases/download/edge/curios-oci-amd64.tar.gz
Connecting to github.com (140.82.121.3:443)
wget: note: TLS certificate validation not implemented
Connecting to objects.githubusercontent.com (185.199.109.133:443)
saving to 'curios-oci-amd64.tar.gz'
curios-oci-amd64.tar 100% |*********************************| 7091k  0:00:00 ETA
'curios-oci-amd64.tar.gz' saved
admin@example:/var/tmp$ ll
total 7104
drwxr-xr-x    3 root     root          4096 Mar 27 14:22 ./
drwxr-xr-x   14 root     root          4096 Mar 27 11:57 ../
-rw-r--r--    1 root     root       7261785 Mar 27 14:22 curios-oci-amd64.tar.gz
drwx------    6 frr      frr           4096 Mar 27 11:57 frr/

Importing the image into Podman can be done either from the CLI admin-exec context ...

admin@example:/var/tmp$ cli
admin@example:/> container load /var/tmp/curios-oci-amd64.tar.gz name curios:edge

Tip

The name curios:edge is the tag you give the imported (raw) archive which you can then reference in your container image configuration: set image curios:edge.

... or by giving the container configuration the full path to the OCI archive, which helps greatly with container upgrades (see below):

admin@example:/config/container/system/> set image oci-archive:/var/tmp/curios-oci-amd64.tar.gz

Checksum Example:

admin@example:/> configure
admin@example:/config/> edit container sys
admin@example:/config/container/sys/> set hostname sys
admin@example:/config/container/sys/> set image ftp://192.168.122.1/curios-oci-amd64-v24.05.0.tar.gz
admin@example:/config/container/sys/> set checksum
    md5 sha256 sha512
admin@example:/config/container/sys/> set checksum sha256 4f01077036527498ed910f1a3e80645ae3eff629d10043cf80ebc6850c99c629
admin@example:/config/container/sys/> leave
admin@example:/> copy running-config startup-config
admin@example:/> show container
CONTAINER ID  IMAGE                                             COMMAND               CREATED         STATUS        PORTS       NAMES
b02e945c43c9  localhost/curios-oci-amd64-v24.05.0:latest                              5 seconds ago   Up 5 seconds              sys

admin@example:/> show log
...
Nov 20 07:24:56 example container[5040]: Fetching ftp://192.168.122.1/curios-oci-amd64-v24.05.0.tar.gz
Nov 20 07:24:56 example container[5040]: curios-oci-amd64-v24.05.0.tar.gz downloaded successfully.
Nov 20 07:24:56 example container[5040]: curios-oci-amd64-v24.05.0.tar.gz checksum verified OK.
Nov 20 07:24:57 example container[5040]: Cleaning up extracted curios-oci-amd64-v24.05.0
Nov 20 07:24:57 example container[5040]: podman create --name sys --conmon-pidfile=/run/container:sys.pid --read-only --replace --quiet --cgroup-parent=containers  --restart=always --systemd=false --tz=local --hostname sys --log-driver k8s-file --log-opt path=/run/containers/sys.fifo --network=none curios-oci-amd64-v24.05.0
Nov 20 07:24:57 example container[3556]: b02e945c43c9bce2c4be88e31d6f63cfdb1a3c8bdd02179376eb059a49ae05e4

Understanding Image Tags

Docker images use tags to identify different versions of the same image. Understanding the difference between mutable and immutable tags is important for managing container upgrades effectively.

Mutable Tags

Tags like :latest, :edge, or :stable are mutable — they point to different images over time as new versions are published to the registry.

Advantages:

  • Convenient: upgrade without changing configuration
  • Simple: use the CLI command container upgrade NAME to get the latest version,
    there is even a convenient RPC for controlling the remotely
  • Good for: development, testing, and systems that auto-update

Trade-offs:

  • Less reproducible: different systems may run different versions
  • Less predictable: upgrades happen when you pull, not when you plan
  • Harder to rollback: previous version may no longer be available

Example mutable tags:

docker://nginx:latest          # Always points to newest release
docker://myapp:edge            # Development/bleeding edge version
oci-archive:/var/tmp/app.tar   # Local archive that may be replaced

Immutable Tags

Version-specific tags like :v1.0.1, :24.11.0, or digest references like @sha256:abc123... are immutable — they always reference the exact same image content.

Advantages:

  • Reproducible: all systems run identical versions
  • Predictable: upgrades only happen when you change configuration
  • Auditable: clear history of what ran when
  • Good for: production, compliance, and controlled deployments

Trade-offs:

  • More explicit: must update configuration to upgrade
  • Requires planning: need to know which version to use

Example immutable tags:

docker://nginx:1.25.3          # Specific version number
docker://myapp:v2.1.0          # Semantic version tag
docker://nginx@sha256:abc123   # Cryptographic digest (most immutable)

Tip

Best practice for production: Use specific version tags (:v1.0.1) rather than mutable tags (:latest). This ensures all your systems run identical software and upgrades happen only when you decide.

Upgrading Container Images

Up-to-date Shield

The applications in your container are an active part of the system as a whole, so make it a routine to keep your container images up-to-date!

How Container Lifecycle Works

Infix intelligently manages container lifecycles to provide a smooth experience while minimizing unnecessary work:

At first setup: When you configure a container for the first time, Infix fetches the image (if needed) and creates the container instance.

At boot time: Infix checks if the container needs to be recreated by comparing checksums for:

  • The image archive that the container was built from
  • The container configuration script

When configuration changes: If you modify any container settings (network, volumes, environment, etc.), the container is automatically recreated with the new configuration.

When explicitly upgraded: Using the container upgrade command forces a fresh pull of the image and recreates the container.

This means that in most cases, containers persist across reboots and are only recreated when actually necessary. Your container's state stored in volumes is preserved across recreations. Since Infix containers use a read-only root filesystem, any changes written outside of volumes or the writable paths provided by Podman (/dev, /dev/shm, /run, /tmp, /var/tmp) will be lost when the container is recreated.

Method 1: Upgrading Immutable Tags

When using version-specific tags, you upgrade by explicitly changing the image reference in your configuration:

admin@example:/> configure
admin@example:/config/> edit container web
admin@example:/config/container/web/> set image docker://nginx:1.25.3
admin@example:/config/container/web/> leave

What happens:

  1. Podman pulls the new image in the background (if not already present)
  2. Your container is automatically stopped
  3. The container is recreated with the new image
  4. The container is started with your existing volumes intact

Example: Upgrading from one version to another:

admin@example:/> configure
admin@example:/config/> edit container system
admin@example:/config/container/system/> show image
image ghcr.io/kernelkit/curios:v24.11.0;
admin@example:/config/container/system/> set image ghcr.io/kernelkit/curios:v24.12.0
admin@example:/config/container/system/> leave
admin@example:/> show log
...
Dec 13 14:32:15 example container[1523]: Pulling ghcr.io/kernelkit/curios:v24.12.0...
Dec 13 14:32:18 example container[1523]: Stopping old container instance...
Dec 13 14:32:19 example container[1523]: Creating new container with updated image...
Dec 13 14:32:20 example container[1523]: Container system started successfully

Method 2: Upgrading Mutable Tags

For images using mutable tags like :latest or :edge, use the container upgrade command:

admin@example:/> container upgrade NAME

This command:

  1. Stops the running container
  2. Pulls the latest version of the image from the registry
  3. Recreates the container with the new image
  4. Starts the container automatically

Example using registry:

admin@example:/> container upgrade system
system
Trying to pull ghcr.io/kernelkit/curios:edge...
Getting image source signatures
Copying blob 07bfba95fe93 done
Copying config 0cb6059c0f done
Writing manifest to image destination
Storing signatures
0cb6059c0f4111650ddbc7dbc4880c64ab8180d4bdbb7269c08034defc348f17
system: not running.
59618cc3c84bef341c1f5251a62be1592e459cc990f0b8864bc0f5be70e60719

Example using local OCI archive:

An OCI archive image can be upgraded in a similar manner. First, get the new archive onto the system (see Container Images section above), then, provided the oci-archive:/path/to/archive format is used in your configuration, call the upgrade command:

admin@example:/> container upgrade system
Upgrading container system with local archive: oci-archive:/var/tmp/curios-oci-amd64.tar.gz ...
7ab4a07ee0c6039837419b7afda4da1527a70f0c60c0f0ac21cafee05ba24b52

OCI archives can also be fetched from ftp/http/https URLs. In that case, the upgrade works the same way as a registry image — Infix downloads the new archive and recreates the container.

Embedded Container Images

Tip

Containers running from OCI images embedded in the operating system, e.g., /lib/oci/mycontainer.tar.gz, are automatically kept in sync with the Infix system image version.

How it works: When you build a custom Infix image with embedded OCI archives, those containers will be upgraded whenever you upgrade the Infix operating system itself. At boot, Infix checks if the embedded image has changed and automatically recreates the container if needed.

Example: default builds of Infix include a couple of OCI images for reference, one is /lib/oci/curios-nftables-v24.11.0.tar.gz, but there is also a symlink called curios-nftables-latest.tar.gz in the same directory, which is what the Infix regression tests use in the image configuration of the container. When the system is upgraded and the embedded image changes, the test containers are automatically recreated with the new version.

This approach ensures your embedded containers always match your system version without any manual intervention.

Capabilities

An unprivileged container works for almost all use-cases, but there are occasions where they are too restricted and users start looking for the privileged flag. Capabilities offers a middle ground.

For example, a system container from which ping does not work:

admin@example:/config/container/system/> edit capabilities
admin@example:/config/container/system/capabilities/> set add net_raw
admin@example:/config/container/system/capabilities/> end
admin@infix-00-00-00:/config/container/system/> show
...
capabilities {
  add net_raw;
}
...

Infix supports a subset of all capabilities that are relevant for containers. Please note, that this is an advanced topic that require time and analysis of your container application to figure out which capabilities you need.

Networking and Containers

By default, unlike other systems, persistent2 containers have no networking enabled. All network access has to be set up explicitly. Currently two types of of container networks are supported:

  • host: an managed host interface, e.g., one end of a VETH pair, or even a physical interface
  • bridge: an IP masquerading bridge

In the former the interface is delegated to (moved into) the container, while in the latter a VETH pair is automatically created by Podman and one end delegated to the container, while the other end is assigned to the bridge (see the next section).

Tip

For more information on VETH pairs, see the Networking Guide.

Container Bridge

A container bridge is what most container setups use and users want.

IP Masquerading Container Bridge

The difference from a regular bridge is that the container runtime fully manages them -- connecting containers with automatically created VETH pairs (look at the bridge port names) and setting up firewall rules between the host and other containers, as well as managing port forwarding. This transparent background management is what makes container use seem to be so simple.

All interface configuration is done in configure context.

admin@example:/> configure
admin@example:/config> edit interface docker0
admin@example:/config/interface/docker0/> set container-network
admin@example:/config/interface/docker0/> leave

There is more to this story. When using the CLI, and sticking to common interface nomenclature, Infix helps you with some of the boring stuff. E.g., creating a new interface with a name like brN or dockerN automatically infers the interface types, which you would otherwise have to set manually:

admin@example:/config/interface/docker0/> set type bridge
admin@example:/config/interface/docker0/> set container-network type bridge

Important

When configuring the system via an API such as NETCONF or RESTCONF, no settings are inferred. Instead it is up to the caller to fully define the desired setup. This makes the CLI very useful for first setup and then extracting the resulting XML from the shell using the cfg -X command.

We have to declare the interface as a container network, ensuring the interface cannot be used by the system for any other purpose. E.g., a container host interface is supposed to be used by a container, by declaring it as such we can guarantee that it would never accidentally be added as a bridge or lag port. Hence, to move an interface currently set as a bridge-port it must be removed from the bridge before being given to a container.

The default subnet for a container bridge is 172.17.0.0/16, the bridge takes the .1 address and hand out the rest of the range to containers in a round-robin like fashion. A container with this network get an automatically created VETH pair connection to the bridge and a lot of other networking parameters (DNS, default route) are set up.

Some of the defaults of a container bridge can be changed, e.g., instead of set container-network type bridge, above, do:

admin@example:/config/interface/docker0/> edit container-network
admin@example:/config/interface/docker0/container-network/> set type bridge
admin@example:/config/interface/docker0/container-network/> edit subnet 192.168.0.0/16
admin@example:/config/interface/docker0/container-network/subnet/192.168.0.0/16/> set gateway 192.168.255.254
admin@example:/config/interface/docker0/container-network/subnet/192.168.0.0/16/> end
admin@example:/config/interface/docker0/container-network/> edit route 10.0.10.0/24
admin@example:/config/interface/docker0/container-network/route/10.0.10.0/24/> set gateway 192.168.10.254
admin@example:/config/interface/docker0/container-network/route/10.0.10.0/24/> end
admin@example:/config/interface/docker0/container-network/> end
admin@example:/config/interface/docker0/> leave

Other network settings, like DNS and domain, use built-in defaults, but can be overridden from each container. Other common settings per container is the IP address and name of the network interface inside the container. The default, after each stop/start cycle, or reboot of the host, is to name the interfaces eth0, eth1, in the order they are given in the network list, and to give the container the next address in a bridge. Below an example of a system container calls set network interface docker0, here we show how to set options for that network:

admin@example:/config/container/ntpd/> edit network interface docker0
admin@example:/config/container/ntpd/network/interface/docker0/>
admin@example:/config/container/ntpd/network/interface/docker0/> set option
<string>  Options for masquerading container bridges.
admin@example:/config/container/ntpd/network/interface/docker0/> help option
NAME
        option <string>

DESCRIPTION
        Options for masquerading container bridges.

        Example: ip=1.2.3.4            -- request a specific IP (IPv4 or IPv6)
                 mac=00:01:02:c0:ff:ee -- set fixed MAC address in container
                 interface_name=foo0   -- set interface name inside container

admin@example:/config/container/ntpd/network/interface/docker0/> set option ip=172.17.0.2
admin@example:/config/container/ntpd/network/interface/docker0/> set option interface_name=wan
admin@example:/config/container/ntpd/network/interface/docker0/> leave

Container Host Interface

Another common use-case is to move network interfaces into the network namespace of a container1. This of course works with plain Ethernet interfaces as well, but here we will use one end of a VETH pair as an example.

The network option setting is available also for this case, but only the interface_name=foo0 option works. Which is still very useful. To set:

  • IP address, use IPv4/IPv6 settings in the interface settings
  • MAC address, to use the custom-phys-address in the interface settings

For an example of both, see the next section.

Routed Setup

In this routed setup we reserve 192.168.0.0/24 for the network between the host and the ntpd container.

Basic VETH pair connecting ntpd container.

Configuration is a straight-forward VETH pair setup where we name the container-end of pair ntpd. This is just a convenience for us when reading the configuration later. The real action happens on the last line where we declare the ntpd end as a container network interface:

admin@example:/config/> edit interface veth0
admin@example:/config/interface/veth0/> set veth peer ntpd
admin@example:/config/interface/veth0/> set ipv4 address 192.168.0.1 prefix-length 24
admin@example:/config/interface/veth0/> end
admin@example:/config/> edit interface ntpd
admin@example:/config/interface/ntpd/> set ipv4 address 192.168.0.2 prefix-length 24
admin@example:/config/interface/ntpd/> set custom-phys-address static 00:c0:ff:ee:00:01
admin@example:/config/interface/ntpd/> set container-network

Tip

Notice how you can also set a custom MAC address at the same time.

Adding the interface to the container is the same as before, but since everything for host interfaces is set up in the interfaces context, we can take a bit of a shortcut.

admin@example:/config/container/ntpd/> set network interface ntpd
admin@example:/config/container/ntpd/> leave

Tip

Use the set network interface ntpd option interface_name=foo0 to set the name of the interface inside the container to foo0.

The point of the routed case is that port forwarding from the container in this case is limited to a single interface, not all interfaces as is the default in the masquerading container bridge setup.

Bridged Setup

A perhaps more common case is to bridge the other end of the VETH pair with other physical ports. In this section we show how to add a new pair to give our container two interfaces:

Bridged setup with ntpd container.

We start by adding the second VETH pair:

admin@example:/config/> edit interface veth1a
admin@example:/config/interface/veth1a/> set veth peer veth1
admin@example:/config/interface/veth1a/> set ipv4 address 192.168.1.2 prefix-length 24

Note

The LAN bridge (br1) in this example has IP address 192.168.1.1.

When a container has multiple host interfaces it can often be useful to have a default route installed. This can be added from the host with a 0.0.0.0/0 route on one of the interfaces:

admin@example:/config/interface/veth1a/> set container-network route 0.0.0.0/0 gateway 192.168.1.1
admin@example:/config/interface/veth1a/> show
type veth;
container-network {
  type host;
  route 0.0.0.0/0 {
    gateway 192.168.1.1;
  }
}
veth {
  peer veth1;
}
admin@example:/config/interface/veth1a/> end
admin@example:/config/> set interface veth1 bridge-port bridge br1

Please note, container network routes require the base interface also have a static IP address set. Setting only the route, but no address, means the route is skipped.

Host Networking

The third use-case is host networking, this is where a container share the network namespace of the host. An example here could be a nftables or ntpd container -- single applications which add core functionality to the host operating system.

The host networking setup cannot be combined with any other network.

For an example, see below.

Mounts and Volumes

It is possible to mount files, directories, and even files matching a glob, into a container. This gives precise control over the container's file system:

admin@example:/config/container/system/> edit mount leds
admin@example:/config/container/system/mount/leds> set source /sys/class/leds
admin@example:/config/container/system/mount/leds> set target /sys/class/leds
admin@example:/config/container/system/mount/leds> end
admin@example:/config/container/system/>

Any type of file can be bind mounted into the container, just watch out for permissions though. In the example above, /sys/class/leds is not writable from a container unless it runs in privileged mode. For plain configuration files you get more freedom, and your container can rely on, e.g., inotify events to trigger reloading its services when you change the file on the host.

So it depends on the container, and indeed your overall setup, what to use. An intriguing option is Content Mounts, which when changed also trigger a container restart.

Other times volumes are a better fit. A volume is an automatically created read-writable entity that follows the life of your container.

admin@example:/config/container/ntpd/> set volume varlib target /var/lib

Volumes are persistent across both reboots and upgrades of the base image. They are created by Podman when the container first starts up, unlike a regular bind mount it synchronizes with the contents of the underlying container image's path at first use. I.e., "bind-mount, if empty: then rsync".

Note

Infix support named volumes (only), and it is not possible to share a volume between containers. All the tricks possible with volumes may be added in a later release.

Volume Management

Volumes are persistent storage that survive container restarts and image upgrades, making them ideal for application data. However, this also means they are not automatically removed when a container is deleted from the configuration.

This design choice prevents accidental data loss, especially in scenarios where:

  • A container is temporarily removed and re-added with the same name
  • A container is replaced with a different configuration but same name
  • System upgrades or configuration changes affect container definitions

To clean up unused volumes and reclaim disk space, use the admin-exec command:

admin@example:/> container prune
Deleted Images
...
Deleted Volumes
ntpd-varlib
system-data

Total reclaimed space: 45.2MB

The container prune command safely removes:

  • Unused container images
  • Volumes not attached to any container (running or stopped)
  • Other unused container resources

Tip

You can monitor container resource usage with the command:

admin@example:/> show container usage

This displays disk space used by images, containers, and volumes, helping you decide when to run the prune command.

To see which volumes exist and which containers use them:

admin@example:/> show container volumes

Content Mounts

Content mounts are a special type of file mount where the file contents is stored with the container configuration. This can be very useful when deploying similar systems at multiple sites. When the host loads its startup-config (or even factory-config) a temporary file is created using the decoded base64 data from the content node.

admin@example:/config/container/ntpd/> edit mount ntpd.conf
admin@example:/config/container/ntpd/mount/ntpd.conf> text-editor content
... interactive editor starts up ...
admin@example:/config/container/ntpd/mount/ntpd.conf> set target /etc/ntpd.conf
admin@example:/config/container/ntpd/mount/ntpd.conf> end
admin@example:/config/container/ntpd/>

The editor is a small Emacs clone called Mg, see the built-in help text, or press Ctrl-x Ctrl-c to exit and save. When the editor exits the contents are base64 encoded and stored in the candidate datastore.

Note

Since these files are always recreated when the host is restarted, changes made by the container are not preserved, or saved back to the host's startup-config.

Infix has three different text editors available. For more information, see CLI Text Editor.

Example Containers

System Container

Let's try out what we've learned by setting up a system container, a container providing multiple services, using the docker0 interface we created previously:

admin@example:/> configure
admin@example:/config> edit container system
admin@example:/config/container/system/> set image ghcr.io/kernelkit/curios:edge
admin@example:/config/container/system/> set network interface docker0
admin@example:/config/container/system/> set publish 222:22
admin@example:/config/container/system/> leave

Note

Ensure you have a network connection to the registry. If the image cannot be pulled, creation of the container will be put in a queue and be retried every time there is a change in the routing table, e.g., default route is added, and every 60 seconds.

Provided the image is downloaded successfully, a new system container now runs behind the docker0 interface, forwarding container port 22 to port 222 on all of the host's interfaces. (See help publish in the container configuration context for the full syntax.)

Available containers can be accessed from admin-exec:

admin@example:/> show container
CONTAINER ID  IMAGE                          COMMAND     CREATED       STATUS       PORTS                 NAMES
439af2917b44  ghcr.io/kernelkit/curios:edge              41 hours ago  Up 16 hours  0.0.0.0:222->222/tcp  system

This is a system container, so you can "attach" to it by starting a shell (or logging in with SSH):

admin@example:/> container shell system
root@439af2917b44:/#

Notice how the hostname inside the container changes. By default the container ID (hash) is used, but this can be easily changed:

root@439af2917b44:/# exit
admin@example:/> configure
admin@example:/config/> edit container system
admin@example:/config/container/system/> set hostname sys101
admin@example:/config/container/system/> leave
admin@example:/> container shell system
root@sys101:/#

In fact, the container hostname setting supports the same format specifiers as the host's hostname setting:

  • %i: OS ID, from /etc/os-release, from Menuconfig branding
  • %h: Default hostname, from /etc/os-release, from branding
  • %m: NIC specific part of base MAC, e.g., to c0-ff-ee
  • %%: Literal %

The most useful combination is probably "container-name-%m", which in this example give the container hostname container-name-c0-ff-ee.

Application Container: nftables

Infix currently does not have a native firewall configuration, and even when it does it will never expose the full capabilities of nftables. For advanced setups, the following is an interesting alternative.

admin@example:/> configure
admin@example:/config> edit container nftables
admin@example:/config/container/nftables/> set image ghcr.io/kernelkit/curios-nftables:edge
admin@example:/config/container/nftables/> set network host
admin@example:/config/container/nftables/> set privileged
admin@example:/config/container/nftables/> edit mount nftables.conf
admin@example:/config/container/nftables/mount/nftables.conf/> set target /etc/nftables.conf
admin@example:/config/container/nftables/mount/nftables.conf/> text-editor content
... interactive editor starts up where you can paste your rules ...
admin@example:/config/container/nftables/mount/nftables.conf/> leave

Notice how we set network host, so the container can see and act on all the host's interfaces, and that we also have to run the container in privileged mode.

Application Container: ntpd

The default NTP server/client in Infix is Chrony, a fully working and capable workhorse for most use-cases. However, it does not support a feature like multicasting, for that you need ISC ntpd.

As we did with nftables, previously, we can use host networking and set up a read-only config file that is bind-mounted into the container's file system and store in the host's startup-config. However, ntpd also saves clock drift information in /var/lib/ntpd, so we will also use volumes in this example.

admin@example:/> configure
admin@example:/config> edit container ntpd
admin@example:/config/container/ntpd/> set image ghcr.io/kernelkit/curios-ntpd:edge
admin@example:/config/container/ntpd/> set network interface ntpd    # From veth0 above
admin@example:/config/container/ntpd/> edit mount ntp.conf
admin@example:/config/container/ntpd/mount/ntp.conf/> set target /etc/ntp.conf
admin@example:/config/container/ntpd/mount/ntp.conf/> text-editor content
... interactive editor starts up where you can paste your rules ...
admin@example:/config/container/ntpd/mount/ntp.conf/> end
admin@example:/config/container/ntpd/> edit volume varlib
admin@example:/config/container/ntpd/volume/varlib/> set target /var/lib
admin@example:/config/container/ntpd/volume/varlib/> leave
admin@example:/> copy running-config startup-config

The ntp.conf file is stored in the host's startup-config and any state data in the container's /var/lib is retained between reboots and across image upgrades.

Advanced

This section covers advanced, and sometimes dangerous, topics. Please read any warnings and always consider the security aspects.

Running Host Commands From Container

SSH login with keys is very handy, both remote scripting friendly and secure, but it does require a few extra configuration steps. The way to set it up is covered in part in SSH Authorized Key.

Another insecure approach is to access the host system directly, bypassing the namespaces that make up the boundary between host and container.

Caution

Please note, this completely demolishes the isolation barrier between container and host operating system. It is only suitable in situations where the container serves more as a unit of distribution rather than as a separate component of the system. Strongly recommended to use this only in trusted setups! Consider also limiting the time frame in which this is active!

First, enable Privileged mode, this unlocks the door and allows the container to manage resources on the host system. An example is the nftables container mentioned previously.

admin@example:/config/container/system/> set privileged

Second, mount the host's /proc/1 directory to somewhere inside your container. Here we pick /1:

admin@example:/config/container/system/> edit mount host
admin@example:/config/container/system/mount/host/> set source /proc/1
admin@example:/config/container/system/mount/host/> set target /1
admin@example:/config/container/system/mount/host/> leave

Third, from inside the container, use the host's PID 1 namespaces with the nsenter3 command to slide through the container's walls. Here we show two example calls to hostname, first the container's own name and then asking what the hostname is on the host:

root@sys101:/# hostname
sys101
root@sys101:/# nsenter -m/1/ns/mnt -u/1/ns/uts -i/1/ns/ipc -n/1/ns/net hostname
example

One use-case for this method is when extending Infix with a management container that connects to other systems. For some tips on how to control an Infix system this way, see Scripting Infix.

Container Requirements

In addition to general best practices for container images, there are a few more things to consider when targeting embedded systems:

If the Docker documentation is not enough, there are plenty of guides online with examples on how to create your own container image. For the more advanced, please see the next section.

Advanced Users

Most people prefer their system containers small, often based on Alpine Linux, or similar, with only a few small applications, including their own, and an SSH server perhaps. For some developers, even this is too big, so they roll their own from source. This section is for you.

Depending on your needs, here is a checklist:

  • you need something that can forward signals, e.g.,
  • tini
  • Bash only, or
  • BusyBox init, a classic most embedded developers know, but read on ...
  • a system container only need the bare necessities of a system bringup
  • E.g., BusyBox's init, but not everything
  • Some of the networking is set up by Podman and CNI for you, but you may want to run a DHCP client?
  • Do not rename interfaces inside the container, use the dedicated interface_name option in the configuration instead
  • Remember, Podman provides a tmpfs for all critical system paths: /dev, /dev/shm, /run, /tmp, and /var/tmp, so you don't need to clean or set up any of these mount points

Examples using tini and BusyBox init are available from the KernelKit curiOS project. It is a small Buildroot based container image builder that generates OCI compatible image tarballs without any tools from Docker or Podman -- ready-made images exist for testing on both AMD64 and ARM64 targets, as well as docker pull images and and OCI tarballs with SHA256 checksums for integrity checking.

Finally, if you build your own version of Infix, and embed OCI tarballs in the system image, then see the tip at the end of Upgrading a Container Image (above).

  1. Something which the container bridge network type does behind the scenes with one end of an automatically created VETH pair. ↩

  2. this does not apply to the admin-exec command container run. This command is intended to be used for testing and evaluating container images. Such containers are given a private network behind an IP masquerading bridge. ↩

  3. The nsenter program is available from either the util-linux package in Debian/Ubuntu/Mint, or in BusyBox. Note, however, it may not be enabled by default in BusyBox. ↩
